Murrelektronik keeps your systems reliably connected with a complete range of connectivity and I/O solutions. Their offerings include cordsets in M8, M12, RJ45, 7/8″, and DIN configurations, along with splitters and field-wireable connectors for flexible installation. They also provide digital, analog, and IO-Link-compatible I/O products, Ethernet/IP connectivity solutions, and dependable power supplies to support a wide range of industrial applications.
Choose from popular connectivity, I/O and Power supply options available for immediate shipment from our Broadview Heights, OH facility to you next day via UPS Ground.
Touch & drag tables left/right to view more data.
| Cable Length | Part Number | Item Image | Description |
|---|---|---|---|
| 2m | 7000-12221-0140200 |  | Single Ended Female Straight Connector, A-coded M12 four-wire |
| 5m | 7000-12221-0140500 | ||
| 10m | 7000-12221-0141000 | ||
| 2m | 7000-12341-0140200 |  | Single Ended female 90 degree Connector, A-coded M12 four wire |
| 5m | 7000-12341-0140500 | ||
| 10m | 7000-12341-0141000 | ||
| 2m | 7000-40021-0140200 |  | Male to Female straight Extension Cable |
| 5m | 7000-40021-0140500 | ||
| Fieldwireable | 7000-12601-0000000 |  | Female 4-pin fieldwireable, IDC terminals |
| Fieldwireable | 7000-12741-0000000 |  | Male 4-pin M12 fieldwireable, screw terminals |
| Fieldwireable | 7000-12941-0000000 |  | Female 4-pin fieldwireable, screw terminals |
| Fieldwireable | 7000-12781-0000000 |  | Male 4-pin two-cable fieldwireable, screw terminals |
| Splitter | 7000-41131-0000000 |  | Splitter, 2x 4-pin female to 1x 4pin male. Pins 1 and 3 are common to all connectors; pin 4 of female connectors land to pin 2 and 4 of male. Commonly used with I/O blocks. Splitters will fit both G3 I/O and Murr I/O blocks. |
| Cable Length | Part Number | Item Image | Description |
|---|---|---|---|
| 1m | 7000-40041-0150100 |  |
Single Ended Female Straight Connector, A-coded M12 five-wire |
| 3m | 7000-40041-0150300 | ||
| Fieldwireable | 7000-12761-0000000 |  |
Male 5-pin fieldwireable, screw terminals |
| Fieldwireable | 7000-12961-0000000 |  |
Female 5-pin fieldwireable, screw terminals |
| Cable Length | Part Number | Item Image | Description | |
|---|---|---|---|---|
| 1m | 7000-40041-0150100 | |
Single Ended Female Straight Connector, A-coded M12 five-wire | |
| 3m | 7000-40041-0150300 | |||
| Fieldwireable | 7000-12761-0000000 | |
Male 5-pin fieldwireable, screw terminals | |
| Fieldwireable | 7000-12961-0000000 | |
Female 5-pin fieldwireable, screw terminals |
| Cable Length | Part Number | Item Image | Description |
|---|---|---|---|
| 2m | 7000-08061-0110200 |  |
Single Ended Female Straight Connector, A-coded M8 4-wire |
| 5m | 7000-08061-0110500 | ||
| 10m | 7000-08061-0111000 |
M12 L-coded Power |
||||
| Cable Length | Part Number | Item Image | Description | |
|---|---|---|---|---|
| 5m | 7000-P4221-P040500 |  |
5-Pole L-coded M12 power cable, straight female. Used with Murr 54631 hybrid IO block | |
| 10m | 7000-P4221-P041000 | |||
| 5m | 7000-P4231-P040500 |  |
5-pole L-coded M12 power cable, 90 deg. Used with Murr 54631 hybrid IO block | |
| 10m | 7000-P4231-P041000 | |||
Ethernet/IP Cables |
||||
| 5m | 7700-44711-S4U0500 |  |
D-coded M12 to RJ45. Compatible with all Aventics EIP fieldbus and Murr 54631 hybrid IO block | |
| 10m | 7700-44711-S4U1000 | |||
| fieldwireable | 7000-14521-0000000 |  |
fieldwireable, D-Coded Male 4-pin, IDC | |
Aventics G3 and 580 Power cables |
||||
| 5m | 7700-A4021-1500500 |  |
7/8 4-pin female straight connector, Euro color code (NA color code available upon request). For use with G3 Aux Power connectors | |
| 10m | 7700-A4021-1501000 | |||
| 5m | 7700-A4031-1500500 |  |
7/8 4-pin female 90 deg connector, Euro color code (NA color code available upon request). For use with G3 Aux Power connectors | |
| 10m | 7700-A4031-1501000 | |||
| 5m | 7700-12221-1500500 |  |
4x18awg M12 female straight cable. For use with Aventics 580 series fieldbus. | |
| 10m | 7700-12221-1501000 | |||
| 0.3m | 7700-A4P41-U0C0030 |  |
4-pin 7/8 male to L-coded M12 power adapter. Adapts power cables used with other manufacturer’s port blocks to the L-coded power port on the 54631 | |
| Connector Style | Part Number | Item Image | Description | Pin diagram and dimensions |
|---|---|---|---|---|
| Connector and 5m cable | 7000-18021-6160500 |  |
Form A DIN connector with 24vdc LED (other voltages available) |  |
| Connector Only | 7000-29005-0000000 |  |
||
| Connector and 5m cable | 7000-11081-6160500 | |
Form B DIN connector with 24vdc LED (other voltages available) |  |
| Connector Only | 7000-29805-0000000 | |
On-machine IO |
||||
| Part Number | Description | Item Image | Related Downloads | Notes |
|---|---|---|---|---|
54631 |
Impact67 Pro Hybrid Ethernet/IP I/O block with IO-Link 8 ports each configurable as 2 digital inputs, 2 digital outputs, 1 input and 1 output, or 1 IO-Link channel + 1 output Each IO-Link channel is individually configurable either as a Class A or a Class B channel L-Coded M12 connector provides higher power than competitor blocks, allowing for transmission of up to 16A when daisy-chaining multiple blocks High-current IO ports; an individual port can provide up to 10A of power Refer to Fieldbus Connectivity for stocked power cables and Ethernet/IP cabling. |  |
Product Page on Murr website will provide STEP, EDS, IOLM and User manual files Product Page [Click Here] Rockwell Add-on Instructions for 54631 | |
59719 |
IO-Link Class A hub 8 M12 ports configured for 16 in and 16 out (user selectable) Use stocked cable 7000-40041-0150100 or 7000-40041-0150300 to connect to 54631 IO-Link master Use stocked splitter 7000-41131-0000000 to combine two M12 sensor cables into one port, or 700-41211-0000000 to combine two M8 3-pin sensor cables into one port. |  |
Product Page [click here] | |
59718 |
IO-Link Class B hub 8 M12 ports configured for 16 in and 16 out (user selectable) Use stocked cable 7000-40041-0150100 or 7000-40041-0150300 to connect to 54631 IO-Link master Use stocked splitter 7000-41131-0000000 to combine two M12 sensor cables into one port, or 700-41211-0000000 to combine two M8 3-pin sensor cables into one port. |  |
Product Page [Click Here] | |
8000-88460-0000000 |
Passive 10-point IO Block Passive block with A-Coded 12-wire M12 port for home run to panel Ports 1 and 2 are 2-point ports; ports 3-8 are 1-point ports. Port provided LED indication. Use in conjunction with stocked 12-pin 5m M12 cable 7000-19041-7050500 | |
Product Page [Click Here] | |
7700-A4P41-U0C0030 |
4-pin 7/8 male to L-coded M12 power adapter. 0.3m length Adapts power cables used with other manufacturer’s port blocks to the L-coded power port on the 54631 |  |
||
In-panel IO |
||||
56005 |
Ethernet/IP DIN rail IO with 8 digital inputs Ethernet/IP node with integrated switch Provides 8 PNP input points Snap-together architecture allows users to attach additional IO blocks |  |
Product Page [Click Here] | |
56168 |
16 Digital In + 16 Digital Out module Add to 56005 to expand IO to include 16 digital inputs and 16 digital outputs Equipped with Auxiliary power connection |  |
Product Page [Click Here] | |
56200 |
4 channel Analog IO Module Add to 56005 for IO expansion. User-configurable for 0-10vdc, +/-10vdc, 4-20mA or 0-20mA process signals |  |
Product Page [Click Here] | |
| Part Number | Description | Item Image | Related Link |
|---|---|---|---|
85133 |
24vdc (24-28V adjustable) power supply 5A capacity 100-240VAC input voltage |  |
Product Page [Click Here] |
85135 |
24vdc (24-28V adjustable) power supply 10A capacity 100-240VAC input voltage |  |
Product Page [Click Here] |
